产品 |
型号 | 最大功率 | 组件尺寸 (mm) | 峰值电流Imp(A) | 峰值电压Vmp (V) | 短路电流Isc (A) | 开路电压Voc(V) | 重量 (KG) |
ODA320-36-P | 320W | 1956×992×45 | 8.71 | 36.78 | 9.59 | 44.14 | 23.00 |
ODA310-36-P | 310W | 1956×992×45 | 8.22 | 37.72 | 9.05 | 44.67 | 23.00 |
ODA305-36-P | 305W | 1956×992×45 | 8.12 | 37.58 | 8.68 | 44.64 | 23.00 |
ODA300-36-P | 300W | 1956×992×45 | 8.02 | 37.42 | 8.58 | 44.08 | 23.00 |
ODA295-36-P | 295W | 1956×992×45 | 7.92 | 37.25 | 8.47 | 44.40 | 23.00 |
ODA290-36-P | 290W | 1956×992×45 | 7.83 | 37.08 | 8.37 | 44.32 | 23.00 |
ODA285-36-P | 285W | 1956×992×45 | 7.72 | 36.92 | 8.26 | 44.05 | 23.00 |
ODA280-36-P | 280W | 1956×992×45 | 7.59 | 36.98 | 8.10 | 44.31 | 23.00 |
ODA275-36-P | 275W | 1956×992×45 | 7.49 | 36.72 | 8.01 | 44.24 | 23.00 |
ODA270-36-P | 270W | 1956×992×45 | 7.42 | 36.40 | 7.94 | 44.17 | 23.00 |
ODA265-36-P | 265W | 1956×992×45 | 7.33 | 36.20 | 7.83 | 44.02 | 23.00 |
ODA260-30-P | 260W | 1640×992×40 | 8.21 | 31.70 | 9.03 | 38.04 | 18.60 |
ODA255-30-P | 255W | 1640×992×40 | 8.18 | 31.18 | 8.75 | 37.07 | 18.60 |
ODA250-30-P | 250W | 1640×992×40 | 8.06 | 31.02 | 8.62 | 36.99 | 18.60 |
ODA245-30-P | 245W | 1640×992×40 | 7.98 | 30.85 | 8.50 | 36.91 | 18.60 |
ODA240-30-P | 240W | 1640×992×40 | 7.86 | 30.72 | 8.36 | 36.60 | 18.60 |
ODA235-30-P | 235W | 1640×992×40 | 7.68 | 30.60 | 8.22 | 36.54 | 18.60 |
ODA230-30-P | 230W | 1640×992×40 | 7.58 | 30.36 | 8.11 | 36.42 | 18.60 |
ODA225-30-P | 225W | 1640×992×40 | 7.46 | 30.18 | 7.97 | 36.33 | 18.60 |
ODA220-30-P | 220W | 1640×992×40 | 7.31 | 30.12 | 7.81 | 36.30 | 18.60 |
ODA215-30-P | 215W | 1640×992×40 | 7.19 | 30.00 | 7.66 | 36.24 | 18.60 |
ODA230-27-P | 230W | 1485×990×40 | 8.20 | 28.08 | 8.76 | 33.37 | 17.00 |
ODA225-27-P | 225W | 1485×990×40 | 8.06 | 27.92 | 8.62 | 33.29 | 17.00 |
ODA220-27-P | 220W | 1485×990×40 | 7.93 | 27.76 | 8.48 | 33.21 | 17.00 |
ODA215-27-P | 215W | 1485×990×40 | 7.82 | 27.59 | 8.34 | 32.91 | 17.00 |
ODA210-27-P | 210W | 1485×990×40 | 7.66 | 27.42 | 8.19 | 32.83 | 17.00 |
ODA205-27-P | 205W | 1485×990×40 | 7.53 | 27.32 | 8.02 | 32.77 | 17.00 |
ODA200-27-P | 200W | 1485×990×40 | 7.38 | 27.11 | 7.89 | 32.67 | 17.00 |
ODA195-27-P | 195W | 1485×990×40 | 7.28 | 27.00 | 7.72 | 32.62 | 17.00 |
ODA205-24-P | 205W | 1330×990×35 | 8.25 | 24.99 | 8.78 | 29.68 | 16.4 |
ODA200-24-P | 200W | 1330×990×35 | 8.09 | 24.81 | 8.63 | 29.59 | 16.4 |
ODA195-24-P | 195W | 1330×990×35 | 7.95 | 24.65 | 8.46 | 29.32 | 16.4 |
ODA190-24-P | 190W | 1330×990×35 | 7.79 | 24.48 | 8.30 | 29.23 | 16.4 |
ODA185-24-P | 185W | 1330×990×35 | 7.67 | 24.29 | 8.15 | 29.13 | 16.4 |
ODA180-24-P | 180W | 1330×990×35 | 7.48 | 24.19 | 7.96 | 29.09 | 16.4 |
ODA175-24-P | 175W | 1330×990×35 | 7.33 | 24.00 | 7.80 | 28.99 | 16.4 |
ODA170-24-P | 170W | 1330×990×35 | 7.12 | 24.00 | 7.57 | 28.99 | 16.4 |
ODA150-18-P | 150W | 1485×668×35 | 8.10 | 18.61 | 8.62 | 22.19 | 11.60 |
ODA145-18-P | 145W | 1485×668×35 | 7.86 | 18.45 | 8.41 | 22.00 | 11.60 |
ODA140-18-P | 140W | 1485×668×35 | 7.66 | 18.28 | 8.19 | 21.89 | 11.60 |
ODA135-18-P | 135W | 1485×668×35 | 7.50 | 18.12 | 7.97 | 21.80 | 11.60 |
ODA130-18-P | 130W | 1485×668×35 | 7.27 | 18.00 | 7.72 | 21.74 | 11.60 |
ODA130-18-P | 130W | 1400×678×35 | 7.21 | 18.11 | 7.89 | 21.89 | 10.50 |
ODA120-18-P | 120W | 1250×678×35 | 6.38 | 18.81 | 7.02 | 22.58 | 9.76 |
ODA115-18-P | 115W | 1230×678×35 | 6.22 | 18.50 | 6.65 | 22.14 | 9.70 |
ODA110-18-P | 110W | 1120×678×35 | 5.84 | 18.90 | 6.23 | 22.54 | 8.90 |
ODA105-18-P | 105W | 1120×678×35 | 5.68 | 18.50 | 6.07 | 22.14 | 8.90 |
ODA100-18-P | 100W | 1100×678×35 | 5.43 | 18.50 | 5.78 | 22.14 | 8.80 |
ODA95-18-P | 95W | 1008×678×35 | 5.10 | 18.72 | 5.43 | 22.36 | 8.00 |
ODA90-18-P | 90W | 1008×678×35 | 4.92 | 18.36 | 5.25 | 22.00 | 8.00 |
ODA85-18-P | 85W | 930×678×30 | 4.58 | 18.72 | 4.86 | 22.36 | 7.00 |
ODA80-18-P | 80W | 905×678×30 | 4.40 | 18.25 | 4.69 | 21.96 | 7.20 |
ODA75-18-P | 75W | 770×678×30 | 4.18 | 18.12 | 4.60 | 21.74 | 6.10 |
ODA70-18-P | 70W | 770×678×30 | 3.82 | 18.50 | 4.05 | 22.14 | 6.10 |
ODA65-18-P | 65W | 720×678×30 | 3.49 | 18.83 | 3.69 | 22.46 | 5.50 |
ODA60-18-P | 60W | 690×678×30 | 3.36 | 18.01 | 3.70 | 21.61 | 5.20 |
ODA55-18-P | 55W | 540×860×30 | 3.00 | 18.36 | 3.21 | 22.00 | 5.20 |
ODA50-18-P | 50W | 540×770×30 | 2.70 | 18.50 | 2.89 | 22.14 | 4.50 |
ODA45-18-P | 45W | 540×770×30 | 2.48 | 18.36 | 2.62 | 22.00 | 4.30 |
ODA40-18-P | 40W | 540×620×25 | 2.19 | 18.25 | 2.35 | 21.96 | 4.00 |
ODA35-18-P | 35W | 360×820×25 | 1.93 | 18.50 | 2.02 | 22.14 | 3.40 |
ODA30-18-P | 30W | 360×678×25 | 1.64 | 18.25 | 1.76 | 21.96 | 3.20 |
ODA25-18-P | 25W | 570×356×25 | 1.33 | 18.83 | 1.42 | 22.46 | 2.60 |
ODA20-18-P | 20W | 510×355×20 | 1.10 | 18.25 | 1.17 | 21.96 | 2.20 |
ODA18-18-P | 18W | 355×490×20 | 0.99 | 18.19 | 1.09 | 21.74 | 2.20 |
ODA15-18-P | 15W | 355×390×18 | 0.82 | 18.36 | 0.87 | 22.00 | 1.90 |
ODA10-18-P | 10W | 275×360×18 | 0.55 | 18.25 | 0.59 | 21.96 | 1.30 |
ODA5-18-P | 5W | 195×275×18 | 0.28 | 18.25 | 0.31 | 21.96 | 0.70 |
ODA5-9-P | 5W | 195×275×17 | 0.52 | 9.64 | 0.57 | 11.57 | 0.65 |
ODA3-9-P | 3W | 195×195×17 | 0.33 | 9.24 | 0.36 | 11.09 | 0.48 |
